其他商用交換器 TPLINK SMC 8024 L2

TigerSwitch 24埠10/100/1000,其中4個千兆組合埠(RJ-45/SFP)
► 24 autoMDIX 10/100/1000 ports provide a feature-rich platform for bandwidth-starved networks
► Standalone managed switch in a small footprint
► VLAN with advanced QinQ support
► QoS
► IGMP Snoopin



SMC Tiger Switch 10/100/1000 24埠千兆交換機,是新款設計符合1RU機櫃的大小,專為中小企業設計的機型。

SMC8024L2 24個 Auto MDIX 10/100/1000Mbps 埠,提供超高速Giga的網路傳輸,適合需巨量檔案高速傳輸的使用單位,如數位影音編輯、印刷輸出、醫院、企業數據中心...等。並提供4個Combo端口( RJ-45/SFP )符合當今額外的靈活性應用或網絡的未來擴展使用。

SMC8024L2提供優越的性能強大的48 Gbps的交換矩陣功能,如QoS功能可優先級分配頻寬在Layer2/Layer 4 。還有包括管理功能,如VLAN與802.1Q ,Spanning Tree, LACP協議和IGMP,於多媒體應用。

網路安全性也是重要的關鍵,SMC8024L2提供了靈活的安全功能,例如,支持802.1x , RADIUS , ACL‘s,MAC基礎 埠安全。

本產品適用於各種需求的網路規模,10/100/1000Mbps 千兆超高速乙太網路,滿足各中小企業的網路管理使用需求!






Download
File Name Version Release Date File Size Download
SMC8024L2 產品規格型錄 英文版 2014-02-12 1,310KB



Product Specification
General Features
Physical Interface • 24 10/100/1000BASE-T ports
• 4 Combo SFP ports
Feature • LACP 802.3ad
• VLANs (up to 256)
• QinQ support
• Spanning Tree (802.1D, 802.1w)
• Broadcast Storm Control
• Flow Control
• IGMP Snooping (v1,v2)
• Jumbo Frame (up to 9K)
• ACL’s
• 802.1x
Switching Database 8K MAC address entries
Safety • CSA/NRTL (UL60950, CSA 22.2. NO 60950-1)
• TÜV/GS (EN60950-1)
• CB (IEC60950-1)
Temperature • Operating: 0 to 40oC (32 to 104 oF)
• Storage : -40 to 70oC (-40 to 158oF)
Humdity • Operating: 10% to 90% (non-condensing)
Dimensions • 44.0 x 17.3 x 4.4 cm
• 17.3 x 6.8 x 1.7 in
Weight • 3.72Kg
• 8.44lbs
MTBF • Operating: 10% to 90% (non-condensing)
QoS Features
Priority Queue Scheduling • Supports 4 levels of priority with fl exible
classifi cation and prioritization
• Per port bandwidth management
